- Efficiency of 22.4% matches the N-type 600-650W median
- Power density of 223.6 W/m² is 4.1 W/m² below N-type 600-650W median (227.7 W/m²) - needs more roof space
- Temperature coefficient of -0.29%/°C matches the N-type 600-650W median
- Weight of 29.5 kg (3.0 kg below N-type 600-650W median of 32.5 kg) allows easier transport and roof mounting
- #4098 for efficiency, #1754 for temperature performance out of 11891 panels
Price Offers 0
| Shop | Country | Price | Price/kWp |
|---|
Series Tiger Neo 78HL4-(V) (Mono-facial module, N-type) 5 variants
Jinko Solar's Tiger Neo 78HL4-(V) series are N-type monocrystalline modules engineered for maximum energy yield in installations operating under conditions far from ideal. The use of N-type cells minimizes light-induced degradation, translating to more stable long-term performance, which appeals to investors focused on realistic returns rather than just catalog power ratings. In practice, these panels are distinguished by their high efficiency under low-light conditions and lower susceptibility to performance losses over time, making them ideal for locations with frequent cloud cover or less favorable roof orientations.
Additionally, the application of SMBB technology enhances current collection and reduces losses during partial shading, while PID resistance is crucial for installations operating under demanding electrical and environmental conditions. Thanks to its robust construction and resistance to demanding external factors, this series is well-suited for large commercial installations and utility-scale PV farms, where reliability, consistent parameter performance, and predictable energy output over years are paramount.
Electrical Parameters (STC)
| Nominal Power (Pmax) | 625 Wp |
| Module Efficiency | 22.36% |
| Voltage at Max Power (Vmpp) | 47.14 V |
| Current at Max Power (Impp) | 13.26 A |
| Open Circuit Voltage (Voc) | 56.55 V |
| Short Circuit Current (Isc) | 13.92 A |
| Max System Voltage | 1500 V |
Temperature Coefficients
| Temp. Coeff. Pmax | -0.290%/°C |
| Temp. Coeff. Voc | -0.250%/°C |
| Temp. Coeff. Isc | 0.045%/°C |
| NOCT | 45°C |
Cell Technology
| Cell Type | Monocrystalline |
| Cell Count | 156 |
| Bifacial | No |
| Bifaciality Factor | - |
Dimensions & Weight
| Length | 2465 mm |
| Width | 1134 mm |
| Height | 35 mm |
| Weight | 29.5 kg |
| Area | 2.80 m² |
| Power Density | 223.6 Wp/m² |
Warranty
| Product Warranty | 12 years |
| Performance Warranty | 30 years |
| End-of-Warranty Output | 87.4% |
| First Year Degradation | 1.00% |
| Annual Degradation | 0.40%/year |
