- Efficiency of 22.6% matches the TOPCon 600-650W median
- At 225.8 W/m² power density, roof space requirements are typical for TOPCon 600-650W panels
- Temperature coefficient of -0.30%/°C matches the TOPCon 600-650W median
- Bifaciality factor of 80% can add 4-12% extra yield with reflective mounting surface
- In the top 26% for efficiency among all TOPCon panels
Price Offers 0
| Shop | Country | Price | Price/kWp |
|---|
Series LP182*210-M-66-NB 5 variants
The Leapton LP182*210-M-66-NB series is designed for installations where high energy production from a given area and stable operation in more challenging conditions are crucial. These are dual-sided (bifacial) modules with a dual-glass construction, allowing them to also utilize reflected light from the ground – a significant advantage, especially on bright roofs, membranes, and ground-mounted installations. The use of N-type TOPCon cells results in improved resistance to typical performance losses over time and more predictable performance at high temperatures. Another key feature of this series is high mechanical durability, which is important for snow and wind loads, a significant factor in the Polish climate. The series is also complemented by a longer warranty package, which supports investors seeking a safe return on their investment. The LP182*210-M-66-NB is well-suited for PV farms, large commercial roofs, and projects where maximizing yield is important without increasing the number of modules.
Electrical Parameters (STC)
| Nominal Power (Pmax) | 610 Wp |
| Module Efficiency | 22.58% |
| Voltage at Max Power (Vmpp) | 40.66 V |
| Current at Max Power (Impp) | 15.00 A |
| Open Circuit Voltage (Voc) | 49.05 V |
| Short Circuit Current (Isc) | 15.84 A |
| Max System Voltage | 1500 V |
Temperature Coefficients
| Temp. Coeff. Pmax | -0.300%/°C |
| Temp. Coeff. Voc | -0.250%/°C |
| Temp. Coeff. Isc | 0.046%/°C |
| NOCT | 41°C |
Cell Technology
| Cell Type | Monocrystalline |
| Cell Count | 132 |
| Bifacial | Yes |
| Bifaciality Factor | 80% |
Dimensions & Weight
| Length | 2382 mm |
| Width | 1134 mm |
| Height | 30 mm |
| Weight | 33.5 kg |
| Area | 2.70 m² |
| Power Density | 225.8 Wp/m² |
Warranty
| Product Warranty | 25 years |
| Performance Warranty | 30 years |
| End-of-Warranty Output | 87.4% |
| First Year Degradation | 1.00% |
| Annual Degradation | 0.40%/year |
