- At 22.6% efficiency, this panel is on par with typical TOPCon 600-650W modules
- At 225.8 W/m² power density, roof space requirements are typical for TOPCon 600-650W panels
- At -0.30%/°C, hot weather performance is typical for TOPCon 600-650W panels
- Bifacial design (80% factor) captures reflected light - adds 4-12% yield on ground-mount or white roof
- #3034 for efficiency, #4977 for temperature performance out of 11672 panels
Price Offers 0
| Shop | Country | Price | Price/kWp |
|---|
Series EVO 6R SE6R-66HBD 6 variants
The SunEvo Solar EVO 6R SE6R-66HBD photovoltaic panel series sets new standards for efficiency through the use of advanced N-type cells in TOPCon technology. The innovative use of rectangular cells allows for significantly better power density, which directly translates to maximizing yields from every square meter of surface area. A key distinguishing feature of this series is the bifacial double-sided design, which, combined with double glass, ensures additional energy yield from reflected radiation and extreme durability in harsh conditions. This solution effectively eliminates the problem of light-induced degradation, guaranteeing stable system operation for decades. These panels are primarily dedicated to modern solar farms and large commercial installations where the priority is the lowest cost of energy production. Compared to the competition, this model stands out with an excellent temperature coefficient and high efficiency in diffused light conditions, which is crucial in the Polish climate zone. By investing in the EVO 6R series, users gain the highest resistance to mechanical loads and a modern design that combines aesthetics with uncompromising technology, ensuring energy security at the highest level.
Electrical Parameters (STC)
| Nominal Power (Pmax) | 610 Wp |
| Module Efficiency | 22.58% |
| Voltage at Max Power (Vmpp) | 40.66 V |
| Current at Max Power (Impp) | 15.00 A |
| Open Circuit Voltage (Voc) | 49.05 V |
| Short Circuit Current (Isc) | 15.84 A |
| Max System Voltage | 1500 V |
Temperature Coefficients
| Temp. Coeff. Pmax | -0.300%/°C |
| Temp. Coeff. Voc | -0.250%/°C |
| Temp. Coeff. Isc | 0.046%/°C |
| NOCT | 41°C |
Cell Technology
| Cell Type | Monocrystalline |
| Cell Count | 132 |
| Bifacial | Yes |
| Bifaciality Factor | 80% |
Dimensions & Weight
| Length | 2382 mm |
| Width | 1134 mm |
| Height | 30 mm |
| Weight | 33.5 kg |
| Area | 2.70 m² |
| Power Density | 225.8 Wp/m² |
Warranty
| Product Warranty | 25 years |
| Performance Warranty | 30 years |
| End-of-Warranty Output | 87.4% |
| First Year Degradation | 1.00% |
| Annual Degradation | 0.40%/year |
