Trina Solar TEB-NEGA6ND.48-425 (Silver Grey, RAL9018)
Trina Solar Brand review

TEB-NEGA6ND.48-425 (Silver Grey, RAL9018)

425 Wp TOPCon
ComparePV verdict

Middle of its segment, modest efficiency

Rank 13,239 of 14,005
Compare panels Datasheet PDF
Power (Wp)
425
Typical for its class
Efficiency (%)
15.70
Weak · bottom 1%
Density (Wp/m²)
157.2
Weak · bottom 1%
Temp (%/°C)
-0.290
Typical · median -0.290
Weight (kg)
33.0
Weak · 11.0 kg above median
Warranty (yrs)
25
Weak · bottom 7%

Trina Solar's Colored Dual Glass Module series was designed with building roof and facade integration in mind - where standard black panels mar the architectural design. Its greatest advantage is the ability to choose the color, thanks to the use of colored glass, allowing the PV installation to match the building's style, rather than the other way around. This solution is particularly valued by investors who must balance aesthetic, conservation, or design requirements with actual energy production.

The dual-glass construction increases resistance to material aging and harsh environmental conditions, and also supports fire safety in BIPV applications. In practice, this means more stable performance and a lower risk of operational issues on roofs and facades exposed to wind, humidity, and temperature fluctuations. The modules are based on N-type TOPCon technology, highly regarded for its low degradation and good performance at high temperatures, translating to a more predictable yield over time.

This is the choice for architects, developers, and companies implementing BIPV - from premium rooftops to commercial facades, where both appearance and energy matter.

Ranking

1,218 panels in the segment TOPCon 400-450 W
Metric This panel Median Position in segment Overall rank
Module efficiency 15.70% 22.00% Weak · bottom 1% 13,685
Power density 157.2 220.2 Weak · bottom 1% 13,670
Temperature coefficient -0.290 -0.290 Typical 2,165
Weight per kWp 77.6 51.4 Weak · bottom 2% 13,678
Performance warranty 25 yrs 30 yrs Weak · bottom 7% 9,798
Colour key Strong - top 25% Typical - middle 50% Weak - bottom 25%

Signals from the data

0 positive · 3 caution
Best for

BIPV, commercial and residential.

Not ideal for

Tight roof space, roofs where every square metre has to count and weight-limited structures.

Watch-outs
15.70% module efficiency

Bottom 1% of the TOPCon 400-450 W segment, against a median of 22.00%. Ranked 13,685th in the whole database.

157.2 watts per square metre

Bottom 1% of the TOPCon 400-450 W segment, against a median of 220.2. Ranked 13,670th in the whole database.

77.6 kg per kWp

Bottom 2% of the TOPCon 400-450 W segment, against a median of 51.4. Ranked 13,678th in the whole database.

Notes from the database
  • Module efficiency of 15.7% is 6.3pp below average for TOPCon 400-450W panels (median: 22.0%)
  • Power density of 157.2 W/m² is 63.0 W/m² below TOPCon 400-450W median (220.2 W/m²) - needs more roof space
  • At -0.29%/°C, hot weather performance is typical for TOPCon 400-450W panels
  • Weight of 33.0 kg is 11.0 kg above TOPCon 400-450W median (22.0 kg) - verify structural support
  • In the top 98% for efficiency among all TOPCon panels

Specifications

Open datasheet PDF
Nominal power (Pmax) 425 Wp Nameplate at 1000 W/m², 25 °C
Module efficiency 15.70 % Weak Segment median 22.00%
Vmpp · Impp 40.30 V · 10.55 A Operating point at max power
Voc · Isc 47.50 V · 11.12 A Sizes the string length
Max system voltage 1500 V Longer strings than 1000 V modules
Dimensions 2384×1134×33 mm · 2.70 m² of roof
Weight 33.0 kg Weak Weak · 11.0 kg above median
Coefficient Pmax -0.290 %/°C Typical median -0.290 of its segment
Coefficient Voc · Isc -0.240 · 0.040 %/°C
NOCT 43 °C At 800 W/m², 20 °C ambient
Product warranty 10 years Hardware defects only
Performance warranty 25 years Weak bottom 7% · median 30 yrs
Degradation 1.00 → 0.40 % First year, then annual

Simulations

Live - change any input
Lifetime output & value
30 years at 1200 kWh/kWp/year and €0.50 per kWh
Power in year 30
-
Lifetime energy
-
Energy value
-

Degradation from this panel's own datasheet figures. No inverter, soiling or shading losses.

Heat losses
-0.290 %/°C against a segment median of -0.290
-
Filter these
Size
Panel Power Eff. Temp. Weight Difference
Trina Solar TEB-NEGA6ND.48-425 (Silver Grey, RAL9018) 425 W 15.70% -0.290 33.0 kg You are here
SPR-MAX7-475 475 W 24.00% -0.270 21.1 kg Lighter, +8.3 pp, +15 yr warranty
JST-EDMH-(445-465)W-TD (465W class) 465 W 23.81% -0.300 20.5 kg Lighter, +8.1 pp, +5 yr warranty
JAT54S40-475/LR 475 W 23.80% -0.260 19.3 kg +50 W, lighter, +8.1 pp
TWMNH-48HW475 475 W 23.80% -0.280 23.7 kg +50 W, lighter, +8.1 pp
CHSM48RN(DG)/F-BH-475 475 W 23.80% -0.290 24.5 kg +50 W, lighter, +8.1 pp
AIKO-A475-MCE54Mw 475 W 23.80% -0.260 21.0 kg +50 W, lighter, +8.1 pp
AIKO-A475-MAH54Mw 475 W 23.80% -0.260 21.5 kg +50 W, lighter, +8.1 pp
TEB-NEGA6ND.48-420 (Silver Grey, RAL9018) 420 W 15.50% -0.290 33.0 kg Very close match
TEB-NEGA6ND.48-430 (Silver Grey, RAL9018) 430 W 15.90% -0.290 33.0 kg +0.2 pp
TEB-NEGA6ND.48-545 (Green, RAL6001) 545 W 20.20% -0.290 33.0 kg +120 W, +4.5 pp
TEB-NEGA6ND.48-550 (Green, RAL6001) 550 W 20.30% -0.290 33.0 kg +125 W, +4.6 pp
AIKO-A680-MDE72Mw 680 W 25.20% -0.260 29.0 kg +255 W, +9.5 pp, +5 yr warranty
AIKO-A675-MDE72Mw 675 W 25.00% -0.260 29.0 kg +250 W, +9.3 pp, +5 yr warranty
AIKO-A700-MAE78Dw 700 W 25.00% -0.260 34.5 kg +275 W, +9.3 pp, +5 yr warranty
AIKO-A695-MAE78Dw 695 W 24.90% -0.260 34.5 kg +270 W, +9.2 pp, +5 yr warranty
AIKO-G670-MCH72Mw 670 W 24.80% -0.260 28.2 kg +245 W, +9.1 pp, +5 yr warranty

Found 1119 panels of the same or similar size to this one, within ±10 mm. See them here Found 1125 panels of the same or similar size to this one, within ±25 mm. See them here Found 1202 panels of the same or similar size to this one, within ±50 mm. See them here Found 1911 panels of the same or similar size to this one, within ±100 mm. See them here

Common questions

6 answered
Does the colored glass in Trina Solar Colored Dual Glass Module panels reduce their power output?
Colored glass causes a slight drop in light transmission compared to standard black panels, but N-type TOPCon cells keep this loss to a minimum. The modules still reach a maximum power output of up to 560 Wp, so investors get a color-matched facade or roof without giving up real energy yield - which is the whole point of this series.
What warranty applies to Trina Solar Colored Dual Glass Module panels?
As a Tier 1 manufacturer, Trina Solar provides a 10-year product warranty and a 25-year linear power output warranty. This is standard for modern N-type TOPCon modules and gives investors confidence in stable performance over a quarter century.
Are Colored Dual Glass series panels suitable for building facades (BIPV)?
Yes, that's one of the series' primary applications. The dual-glass construction improves resistance to weathering and supports fire safety required in BIPV installations, while the choice of glass color lets you integrate the panels into a facade without the contrasting black surfaces typical of standard modules.
How does the dual-glass construction differ from a standard panel with a backsheet?
In a dual-glass module, cells are laminated between two glass panes instead of glass and a polymer backsheet. This increases rigidity, protects against moisture and micro-cracks, and extends service life on roofs and facades exposed to wind and temperature swings, at the cost of slightly higher panel weight.
Does TOPCon technology in these panels handle heat better than older PERC cells?
Yes, N-type TOPCon cells have a lower temperature coefficient and slower degradation over time than older P-type PERC cells, so on hot days they lose less power and maintain a more predictable energy yield throughout the system's operating life.
Are Colored Dual Glass modules bifacial?
No, this series uses a monofacial design - the colored glass on the back limits light transmission from the rear side, so the panel generates energy only from its front surface. This is a deliberate trade-off: giving up bifacial gain in favor of the aesthetics required in BIPV and facade projects.
