ECODELTA ECO-410M-60SB
ECODELTA Brand review

ECO-410M-60SB

410 Wp TOPCon
ComparePV verdict

Middle of its segment, modest efficiency

Rank 11,425 of 14,005
Compare panels Datasheet PDF
Power (Wp)
410
Weak · bottom 4%
Efficiency (%)
20.90
Weak · bottom 3%
Density (Wp/m²)
209.2
Weak · bottom 4%
Temp (%/°C)
-0.340
Weak · bottom 5%
Weight (kg)
21.0
Typical · median 22.0 kg
Warranty (yrs)
25
Weak · bottom 7%

The Ecodelta Rays series introduces a new quality to the Polish photovoltaic market, utilizing advanced shingled technology, which eliminates traditional busbars and minimizes gaps between cells. This design directly translates to higher power density and better module efficiency compared to classic solutions with busbar technology. These panels effectively solve the problem of performance drops caused by periodic shading, making them an ideal choice for complex roofs of single-family homes. The innovative construction reduces mechanical stress, providing increased resistance to micro-cracks and extreme weather conditions. For the investor, this means not only higher energy yields but also exceptional full-black aesthetics, where the uniform, dark surface of the modules blends perfectly with modern roofing. Ecodelta Rays stands out from the competition with a reduced risk of hot-spots, which guarantees the safety and longevity of the installation for decades. It is a product aimed at demanding users who expect a combination of technical innovation and elegance, looking for solutions with a low power degradation rate over time. Thanks to precise manufacturing, this series provides a solid foundation for any modern solar power plant, offering maximum return on investment while maintaining the highest visual standards.

Ranking

1,218 panels in the segment TOPCon 400-450 W
Metric This panel Median Position in segment Overall rank
Module efficiency 20.90% 22.00% Weak · bottom 3% 10,072
Power density 209.2 220.2 Weak · bottom 4% 10,077
Temperature coefficient -0.340 -0.290 Weak · bottom 5% 8,778
Weight per kWp 51.2 51.4 Typical 4,595
Performance warranty 25 yrs 30 yrs Weak · bottom 7% 9,798
Colour key Strong - top 25% Typical - middle 50% Weak - bottom 25%

Signals from the data

5 positive · 5 caution
Not ideal for

Tight roof space, roofs where every square metre has to count and hot climates.

Watch-outs
20.90% module efficiency

Bottom 3% of the TOPCon 400-450 W segment, against a median of 22.00%. Ranked 10,072nd in the whole database.

209.2 watts per square metre

Bottom 4% of the TOPCon 400-450 W segment, against a median of 220.2. Ranked 10,077th in the whole database.

-0.340 %/°C temperature coefficient

Bottom 5% of the TOPCon 400-450 W segment, against a median of -0.290. Ranked 8,778th in the whole database.

What owners get
TOPCon N-type + Shingled Architecture Synergy

Two premium technologies combined in a single module: N-type TOPCon cells exhibit LID degradation below 0.25%/year and effective resistance to LeTID, while the shingled architecture using ECA adhesive instead of solder ribbon eliminates thermal stress and microcracks at interconnection points. The net result is a measurably lower annual degradation rate (~0.4%/year vs. ~0.55%/year for PERC).

Up to 21.2% Efficiency – Top of Its Class

Peak efficiency of 21.2% places the RAYS series directly alongside its peer comparables: AE Solar AURORA (21.28%) and Aptos Solar DNA (21.25%). The sub-0.1 percentage point difference is negligible in residential installations; however, on roof areas with limited space, RAYS delivers power density comparable to the leading 54-cell modules on the market.

Full Black with No Visible Busbars – Premium Aesthetics

Shingled cell technology eliminates visible metallic busbars, producing a uniform black surface with no premium charge for a dedicated all-black product line. For the residential segment with dark roof cladding, this represents a significant aesthetic advantage over conventional silver-framed modules.

Partial Shading Tolerance

Splitting cells into parallel-connected strips (shingled architecture) limits the weakest-link effect: localized shading from a chimney, roof window, or antenna affects only the shaded strip rather than the entire cell string. This is a tangible advantage over conventional half-cut PERC modules without power optimizers on complex roof layouts.

25-Year Linear Power Warranty

The 25-year linear power warranty aligns with the premium market standard and ensures predictable energy yield over the full investment horizon of a prosumer system (SPBT typically 7–12 years). The manufacturer has been active since 2002 (over 20 years), which reduces the risk of warrantor insolvency compared to newer brands.

Trade-offs
Product Warranty Limited to 15 Years

A 15-year product warranty falls below the rising market standard – Jinko Solar Tiger Neo, Trina Vertex S+, and REC Alpha all offer 25-year product warranties. Over a 25-year investment horizon, the 10-year gap means no warranty coverage for potential module defects during the second half of the system's operational life.

Monofacial Only – No Bifacial Option Available

The peer comparable LEDVANCE M395~415P54LM-BF-F3 (415 Wp, 21.25%) offers a bifacial construction, potentially generating an additional 5–15% yield on installations with high-albedo surfaces (white membrane, gravel, snow). The RAYS series does not offer a bifacial variant, which may be a limitation when optimizing ground-mount or flat-roof installations.

Notes from the database
  • Module efficiency of 20.9% is 1.1pp below average for TOPCon 400-450W panels (median: 22.0%)
  • 209.2 W/m² power density is 11.0 W/m² below TOPCon 400-450W median (220.2 W/m²) - requires larger installation area
  • Temperature coefficient of -0.34%/°C is 0.05pp worse than TOPCon 400-450W median (-0.29%/°C) - higher losses in summer heat
  • At 21.0 kg, weight matches the TOPCon 400-450W median
  • Ranked #10072 out of 14005 panels for efficiency in the database

Specifications

Open datasheet PDF
Nominal power (Pmax) 410 Wp Nameplate at 1000 W/m², 25 °C
Module efficiency 20.90 % Weak Segment median 22.00%
Vmpp · Impp 38.80 V · 10.57 A Operating point at max power
Voc · Isc 46.60 V · 11.07 A Sizes the string length
Max system voltage 1500 V Longer strings than 1000 V modules
Dimensions 1719×1140×30 mm · 1.96 m² of roof
Weight 21.0 kg Typical Typical · median 22.0 kg
Coefficient Pmax -0.340 %/°C Weak bottom 5% of its segment
Coefficient Voc · Isc -0.270 · 0.040 %/°C
NOCT 42 °C At 800 W/m², 20 °C ambient
Product warranty 15 years Hardware defects only
Performance warranty 25 years Weak bottom 7% · median 30 yrs
End-of-warranty output 84.8 % Equals 336 W guaranteed

Simulations

Live - change any input
Lifetime output & value
30 years at 1200 kWh/kWp/year and €0.50 per kWh
Power in year 30
-
Lifetime energy
-
Energy value
-

Degradation from this panel's own datasheet figures. No inverter, soiling or shading losses.

Heat losses
-0.340 %/°C against a segment median of -0.290
-
Filter these
Size
Panel Power Eff. Temp. Weight Difference
ECODELTA ECO-410M-60SB 410 W 20.90% -0.340 21.0 kg You are here
AIKO-A460-MAH54Mb 460 W 23.60% -0.290 20.5 kg +50 W, cooler, +2.7 pp
JST-EDMH-(445-465)W-TD (460W class) 460 W 23.56% -0.300 20.5 kg +50 W, +2.7 pp, +5 yr warranty
LX-460M/182R-96+ GG 460 W 23.55% -0.260 23.5 kg +50 W, cooler, +2.7 pp
PS-MNB108(HCBF)-460W 460 W 23.53% -0.290 20.5 kg +50 W, cooler, +2.6 pp
JAT54S40-460/LR 460 W 23.50% -0.260 19.3 kg +50 W, cooler, +2.6 pp
LX-460M/182R188-108+ GG 460 W 23.35% -0.290 24.5 kg +50 W, cooler, +2.5 pp
AIKO-455-MAH54Db 455 W 23.30% -0.260 24.0 kg Cooler, +2.4 pp, +5 yr warranty
LR5-54HTH-455M 455 W 23.30% -0.290 20.8 kg +45 W, cooler, +2.4 pp
ECO-395M-60SB 395 W 20.20% -0.340 21.0 kg -15 W, -0.7 pp
ECO-400M-60SB 400 W 20.40% -0.340 21.0 kg -10 W, -0.5 pp
ECO-405M-60SB 405 W 20.70% -0.340 21.0 kg Very close match
ECO-415M-60SB 415 W 21.20% -0.340 21.0 kg +0.3 pp
LR7-54HJD-510M 510 W 25.00% -0.240 23.5 kg +100 W, cooler, +4.1 pp
AIKO-A495-MCE54Mw 495 W 24.80% -0.260 21.0 kg +85 W, cooler, +3.9 pp
LR7-54HJD-505M 505 W 24.70% -0.240 23.5 kg +95 W, cooler, +3.8 pp
AIKO-A490-MCE54Mw 490 W 24.50% -0.260 21.0 kg +80 W, cooler, +3.6 pp

Found 1746 panels of the same or similar size to this one, within ±10 mm. See them here Found 1902 panels of the same or similar size to this one, within ±25 mm. See them here Found 3386 panels of the same or similar size to this one, within ±50 mm. See them here Found 3817 panels of the same or similar size to this one, within ±100 mm. See them here

Common questions

6 answered
What is the shingled cell technology used in Ecodelta Rays panels and why is it superior to conventional busbars?
In Ecodelta Rays panels, TOPCon cells are cut into narrow strips and overlapped like roof shingles, eliminating traditional busbars entirely. This design allows a greater amount of active cell material to fit within the same module footprint, resulting in higher power density and overall module efficiency. An additional benefit is the elimination of thermal bridging at busbar contacts, which is the primary cause of hot spots and cell microcracks in conventional panel designs.
What warranty does the manufacturer offer on Ecodelta Rays photovoltaic panels?
Ecodelta provides two independent warranties for the Rays series: a 15-year product warranty covering material and manufacturing defects, and a 25-year linear power output warranty guaranteeing minimum generation efficiency over a quarter century. These two levels of protection represent a significant advantage when evaluating the total cost of ownership of a PV installation.
Will Ecodelta Rays 415W panels perform well on a roof with partial shading, for example from a chimney or dormer window?
Yes, the Rays series is particularly well-suited for exactly these types of installations. The shingled cell technology means that shading of a single cell strip reduces the output of the entire module to a far lesser extent than in panels with standard busbars. The integrated bypass circuitry operates at the level of individual cell strips rather than entire strings, which means the annual energy yield on complex residential rooftops is noticeably higher than with conventional half-cut modules.
Are Ecodelta Rays panels available exclusively in a full black finish?
The Rays series is designed primarily with full black aesthetics in mind: a black frame, black backsheet, and dark TOPCon cells create a uniform surface that is difficult to distinguish from modern roofing materials. If a standard silver frame is preferred, it is worth contacting your distributor to inquire about variant availability; however, the full black finish is the flagship and most widely available configuration.
What is the peak power output of the Ecodelta Rays module and how does it compare to average panels available on the Polish market?
The flagship module in the Rays series achieves a peak power output of 415 Wp. By combining TOPCon cells with shingled cell technology, the module efficiency exceeds the level achieved by most popular PERC panels currently on the market. This means that the same roof area accommodates more installed watts, which is particularly important where available roof space is limited.
Where are Ecodelta Rays panels manufactured and where is the company headquartered?
Ecodelta (Eco Delta Power Co., Ltd.) is a brand whose global headquarters is based in France. Rays series panels reach the Polish market through domestic photovoltaic distributors. The manufacturer's European operational presence simplifies warranty claim processing and ensures more responsive after-sales support compared to brands operating solely out of Asia.
