480Wp
AIKO AIKO-A480-MAH54Mw
AIKO Review

AIKO-A480-MAH54Mw

Monocrystalline
24.10%
Efficiency
240.9 Wp/m²
Power Density
-0.260%/°C
Temp. Coeff. Pmax chart
426W from 480W
Power after 30 years
  • Efficiency of 24.1% is 0.6pp above the Back Contact 450-500W median (23.5%)
  • 240.9 W/m² power density - 5.7 W/m² more than Back Contact 450-500W median (235.2 W/m²), more power per roof area
  • Temperature coefficient of -0.26%/°C matches the Back Contact 450-500W median
  • Ranked #158 out of 11672 panels for efficiency in the database
Performance Profile
Price Offers 0
Shop Country Price Price/kWp
Series Neostar 2P (AIKO-A-MAH54Mw) 8 variants
Efficiency Range 22.6% - 24.3%
Avg. Efficiency 23.45%
Technology Back Contact
Dimensions 1757 × 1134 mm
Show series description

AIKO Neostar 2P (AIKO-A-MAH54Mw) are modules based on N-type ABC (All Back Contact) cells, meaning a construction without front busbars and conventional metal mesh interconnection. In practice, this means better light utilization and a cleaner, uniform front appearance – particularly valued in rooftop installations for homes and premium buildings. The applied architecture also helps reduce losses associated with temperature, ensuring more stable performance during hot days when many competing panels noticeably lose power.

The Neostar 2P is distinguished by high resistance to microcracks, which is important for long-term operation, transportation, and use on structures exposed to stress. Users also benefit from lower degradation over time, meaning greater predictability in energy production over years and easier planning for investment profitability. This is an excellent choice for those who wish to maximize the use of limited rooftop space and for companies where high output per square meter is crucial. Thanks to its refined aesthetics and ABC technology, the series clearly stands out from standard PERC and classic TOPCon modules.

Panels from the same series differ mainly in power output while having identical dimensions. Learn why →
Electrical Parameters (STC)
Nominal Power (Pmax)480 Wp
Module Efficiency24.10%
Voltage at Max Power (Vmpp)34.86 V
Current at Max Power (Impp)13.78 A
Open Circuit Voltage (Voc)41.30 V
Short Circuit Current (Isc)14.38 A
Max System Voltage1500 V
Temperature Coefficients
Temp. Coeff. Pmax-0.260%/°C
Temp. Coeff. Voc-0.220%/°C
Temp. Coeff. Isc0.050%/°C
NOCT-
Cell Technology
Cell TypeMonocrystalline
Cell Count108
BifacialNo
Bifaciality Factor-
Dimensions & Weight
Length1757 mm
Width1134 mm
Height30 mm
Weight21.5 kg
Area1.99 m²
Power Density240.9 Wp/m²
Warranty
Product Warranty25 years
Performance Warranty30 years
End-of-Warranty Output88.8%
First Year Degradation1.00%
Annual Degradation0.35%/year
Key Specifications
24.10%
Efficiency
480 Wp
Power
-0.26%/°C
Temp Coeff
30 yrs
Warranty
