PVolution Brand review

PVN595-M10TCBB

595 Wp TOPCon Bifacial 85%
ComparePV verdict

Space saver, no clear weak spot

Rank 1,411 of 14,013
Compare panels Datasheet PDF
Power (Wp)
595
Strong · top 5%
Efficiency (%)
23.02
Strong · top 7%
Density (Wp/m²)
230.3
Strong · top 7%
Temp (%/°C)
-0.300
Typical · median -0.290
Weight (kg)
31.0
Typical · median 31.2 kg
Warranty (yrs)
30
Typical · median 30 yrs

The PVolution CORE series is built for anyone who expects more than just high output from their solar panels - durability measured in decades matters just as much. The modules are based on N-Type TOPCon cells, delivering more stable performance at high temperatures and slower degradation compared to older PERC technology. The glass-glass construction shields the cells from moisture and microcracks, allowing the panels to retain a high share of their rated power even after thirty years of operation. The bifacial, dual-glass design also captures light reflected off the roof or ground, meaningfully boosting energy yield without increasing installation footprint. CORE series panels are available in several power variants, making them a good fit for residential rooftops as well as commercial installations and utility-scale solar parks. Their reinforced frame and resistance to snow and wind loads make them a solid choice in more demanding climate conditions. This is a solution for investors who value predictable returns, a low LCOE over the full lifetime of the installation, and the confidence that the panel will keep performing reliably long after competing products' warranty periods have ended.

Ranking

1,016 panels in the segment TOPCon 550-600 W
Metric This panel Median Position in segment Overall rank
Module efficiency 23.02% 22.44% Strong · top 7% 1,791
Power density 230.3 224.4 Strong · top 7% 1,752
Temperature coefficient -0.300 -0.290 Typical 6,086
Weight per kWp 52.1 53.8 Typical 5,536
Performance warranty 30 yrs 30 yrs Typical 21
Colour key Strong - top 25% Typical - middle 50% Weak - bottom 25%

Signals from the data

7 positive · 1 caution
Best for

Commercial and utility-scale.

Strengths
230.3 watts per square metre

Top 7% of the TOPCon 550-600 W segment, against a median of 224.4. Ranked 1,752nd in the whole database.

23.02% module efficiency

Top 7% of the TOPCon 550-600 W segment, against a median of 22.44%. Ranked 1,791st in the whole database.

What owners get
Up to 23.22% efficiency — above peers

The CORE series' peak efficiency (23.22%) exceeds comparable 710 Wp modules from competitors, such as Goldi Solar HELOC PLUS G12 (22.85%) and Talesun TM8G66M (22.9%), delivering higher energy yield on the same roof area.

30-year power warranty

The 30-year power warranty exceeds the market standard for TOPCon, where most Tier-1 manufacturers offer 25 years with retention around 84-86%. This meaningfully lowers the installation's lifetime LCOE.

Glass-glass construction and bifacial design

The dual-glass build protects the N-type TOPCon cells from moisture and micro-cracks, while bifaciality of up to 85% captures reflected light off the ground, boosting yield without increasing installation footprint.

Mechanical resilience in harsh conditions

The reinforced frame withstands snow loads up to 8,000 Pa and wind loads up to 5,400 Pa, making the series a solid choice for demanding climate regions.

Wide power range across 25 variants

Ratings from 430 Wp to 710 Wp across 25 variants allow the series to fit residential rooftops as well as commercial and utility-scale PV installations without switching cell technology.

Trade-offs
Higher degradation than HJT competitors

N-type TOPCon cells degrade faster (roughly 0.40%/year) than the HJT technology used by comparable peer Heliene 132HC G12 HJT SL Bifacial (roughly 0.25%/year), meaning that despite similar starting efficiency (23.22% vs 22.86%), retained capacity over 25-30 years will be lower.

Specifications

Open datasheet PDF
Nominal power (Pmax) 595 Wp Nameplate at 1000 W/m², 25 °C
Module efficiency 23.02 % Strong Segment median 22.44%
Vmpp · Impp 43.03 V · 13.83 A Operating point at max power
Voc · Isc 51.84 V · 14.55 A Sizes the string length
Max system voltage 1500 V Longer strings than 1000 V modules
Dimensions 2278×1134×30 mm · 2.58 m² of roof
Weight 31.0 kg Typical Typical · median 31.2 kg
Cells 144 · TOPCon Monocrystalline
Bifaciality 85 % Rear output as a share of front
Coefficient Pmax -0.300 %/°C Typical median -0.290 of its segment
Coefficient Voc · Isc -0.250 · 0.046 %/°C
NOCT 45 °C At 800 W/m², 20 °C ambient
Product warranty 25 years Hardware defects only
Performance warranty 30 years Typical median 30 yrs · median 30 yrs
End-of-warranty output 87.4 % Equals 520 W guaranteed
Degradation 1.00 → 0.40 % First year, then annual

Simulations

Live - change any input
Lifetime output & value
30 years at 1200 kWh/kWp/year and €0.50 per kWh
Power in year 30
-
Lifetime energy
-
Energy value
-
With bifacial gain
-

Degradation from this panel's own datasheet figures. No inverter, soiling or shading losses.

Heat losses
-0.300 %/°C against a segment median of -0.290
-
Bifacial gain
Rear gain over light concrete: -
-

Model: bifaciality × albedo × 0.6 view factor. A first-order estimate, not a yield simulation.

Alternatives

All PVolution panels
Filter these
Size
Panel Power Eff. Temp. Weight Difference
PVolution PVN595-M10TCBB 595 W 23.02% -0.300 31.0 kg You are here
AIKO-A645-MAE72Mw 645 W 25.00% -0.260 27.0 kg +50 W, lighter, +2.0 pp
LR7-60HVH-560M 560 W 24.80% -0.260 25.0 kg Cooler, lighter, +1.8 pp
AIKO-A640-MAE72Mw 640 W 24.80% -0.260 27.0 kg +45 W, lighter, +1.8 pp
LR7-60HVH-555M 555 W 24.60% -0.260 25.0 kg -40 W, lighter, +1.6 pp
AIKO-A635-MAE72Mw 635 W 24.60% -0.260 27.0 kg +40 W, lighter, +1.6 pp
PVN350-M10TCBB (AGRI) 350 W 13.66% -0.290 30.6 kg -245 W, cooler, -9.4 pp
PVN355-M10TCBB (AGRI) 355 W 13.85% -0.290 30.6 kg -240 W, cooler, -9.2 pp
PVN360-M10TCBB (AGRI) 360 W 14.05% -0.290 30.6 kg -235 W, cooler, -9.0 pp
PVN365-M10TCBB (AGRI) 365 W 14.24% -0.290 30.6 kg -230 W, cooler, -8.8 pp
PVN370-M10TCBB 370 W 14.44% -0.290 30.6 kg -225 W, cooler, -8.6 pp
PVN585-M10TCBB 585 W 22.64% -0.300 31.0 kg -10 W, -0.4 pp
PVN590-M10TCBB 590 W 22.83% -0.300 31.0 kg Very close match
PVN600-M10TCBB 600 W 23.22% -0.300 31.0 kg Very close match
AIKO-A650-MAE72Mw 650 W 25.20% -0.260 27.0 kg +55 W, lighter, +2.2 pp
AIKO-A630-MAH72Dw 630 W 24.40% -0.260 32.5 kg +35 W, cooler, +1.4 pp

Found 2326 panels of the same or similar size to this one, within ±10 mm. See them here Found 2368 panels of the same or similar size to this one, within ±25 mm. See them here Found 2382 panels of the same or similar size to this one, within ±50 mm. See them here Found 2547 panels of the same or similar size to this one, within ±100 mm. See them here

Common questions

6 answered
How does TOPCon cell technology in PVolution CORE panels differ from older PERC panels?
The N-Type TOPCon cells used in the CORE series have a lower annual degradation rate and perform better at high temperatures than P-Type PERC cells. In practice, this means the panel loses less power on hot days and ages more slowly over the years, resulting in higher energy yield throughout the 30-year warranty period.
Does the bifacial glass-glass design of CORE panels actually increase energy production?
Yes, the glass-glass bifacial construction allows the rear side of the module to capture light reflected from the roof, bright ground surfaces, or snow. Depending on the albedo of the mounting surface and installation height, the additional energy gain can range from a few to over a dozen percent compared to a monofacial panel of the same rated power, without increasing roof area.
What warranty comes with PVolution CORE panels and what does it cover?
The CORE series comes with a 30-year product warranty and a 30-year linear power output warranty. This means the manufacturer guarantees both build quality and retention of a high percentage of rated power over three decades, a much longer period than the standard 10-15 years offered on older PERC generation panels.
Are 710 Wp CORE panels suitable for a residential rooftop installation?
Yes, despite the high power output of up to 710 Wp, the CORE series is available in several power variants, so you can choose a module suited to a small rooftop system as well as a large-scale solar farm. The reinforced frame also provides resistance to snow and wind loads, making it a safe choice for demanding climate conditions typical of many rooftops.
Is the glass-glass construction of CORE panels more resistant to microcracks than a standard framed backsheet panel?
Yes, the dual-glass design better protects the cells from moisture and mechanical stress than a traditional backsheet construction. This lowers the risk of microcracks forming during transport, installation, or due to thermal stress, helping the panel retain its original performance longer, as reflected in the extended power warranty.
Is it worth paying more for bifacial TOPCon panels instead of a cheaper PERC panel?
Choosing CORE panels makes sense for investors who evaluate energy cost over the full lifecycle of the installation, not just the upfront price. Lower annual degradation, additional yield from the bifacial effect, and a 30-year warranty reduce LCOE over the long term, despite a higher initial price compared to classic PERC panels with 10-15 year warranties.
