Strong in heat, no clear weak spot
The Hanersun HN18-54HB series is designed for installations where high energy production and a convenient module format are key. A major advantage is the combination of a half-cut construction with MBB technology, which effectively reduces connection losses and improves performance under partial shading. Thanks to high cell density, the module efficiently utilizes available space, and a refined connection architecture minimizes the risk of local overheating.
In practice, this series helps to solve common roofing problems: limited space, variable sun exposure, and the need for stable performance on hot days. It is a good choice for single-family homes and small businesses, but also for projects where repeatability of parameters and efficient logistics are important. Compared to the competition, the HN18-54HB stands out due to its compatibility with popular mounting systems and inverters and its focus on long-term reliability - without unrealistic promises, but with a clearly thought-out module design.
Ranking
Signals from the data
Residential, commercial and shaded-installations.
Top 4% of the PERC 400-450 W segment, against a median of -0.350. Ranked 8,005th in the whole database.
Top 24% of the PERC 400-450 W segment, against a median of 206.2.
The half-cut cell design reduces series resistance, while the multi-busbar (MBB) architecture minimizes current losses across the busbars. In practice, this translates to improved performance under partial shading conditions and a lower risk of localized hot spots compared to full-cell modules with 3–4 busbars.
The maximum module efficiency of 21.25% is equivalent to directly comparable models such as the LEDVANCE M395~415P54LM-BF-F3 (21.25%) and the Aptos Solar DNA 108-Monofacial (21.25%), indicating no energy yield penalty relative to direct competitors in this format (54-cell, 415 Wp).
The series encompasses both PERC and TOPCon variants. TOPCon modules exhibit a lower light-induced degradation (LID) rate and a superior temperature coefficient of power (typically −0.30%/°C vs. −0.35%/°C for PERC), which meaningfully increases annual energy yield in hot climates.
The manufacturer provides a 25-year linear power output warranty — the industry standard shared by all comparable competitors (AE Solar, LEDVANCE, Aptos Solar) — ensuring predictable degradation curves (DCR) for project finance and bankability analyses.
Production was discontinued in 2023. The unavailability of new modules from this series creates challenges for expanding existing installations, limits access to matched replacements in the event of module failure, and poses a risk of serviceability issues once the product warranty expires (12 years).
Hanersun did not achieve BNEF Tier 1 status until Q2 2023 — coinciding with the phase-out of the HN18-54HB series. For most of the production cycle (2021–2022), the manufacturer was absent from the bankable supplier list, which may have complicated project financing and equipment leasing for financial institutions requiring BNEF certification.
The series datasheet specifies Fire Safety Class C under IEC 61730 — the lowest of the three classifications (A/B/C). This may represent a formal constraint for rooftop installations in close proximity to adjacent structures, or for projects where local building codes mandate Class A or Class B compliance.
- At 21.0% efficiency, this panel is on par with typical PERC 400-450W modules
- At 210.0 W/m² power density, this panel generates 3.8 W/m² more per unit area than PERC 400-450W median (206.2 W/m²)
- Temperature coefficient of -0.31%/°C vs median -0.35%/°C means ~2% less power loss at 65°C
- #9944 for efficiency, #8005 for temperature performance out of 14005 panels
Specifications
Datasheet charts
Measured curves published by Hanersun in this model's datasheet. A chart carrying a wattage was measured on that variant alone - only the ones that describe 410 Wp appear here. The rest cover the whole series.
Simulations
Degradation from this panel's own datasheet figures. No inverter, soiling or shading losses.
Found 1783 panels of the same or similar size to this one, within ±10 mm. See them here Found 1914 panels of the same or similar size to this one, within ±25 mm. See them here Found 3392 panels of the same or similar size to this one, within ±50 mm. See them here Found 3970 panels of the same or similar size to this one, within ±100 mm. See them here
