AmoSolar AS530M10-144
AmoSolar Brand review

AS530M10-144

530 Wp PERC
ComparePV verdict

Middle of its segment, needs the roof space

Rank 9,595 of 14,005
Compare panels Datasheet PDF
Power (Wp)
530
Typical for its class
Efficiency (%)
20.51
Weak · bottom 14%
Density (Wp/m²)
205.1
Weak · bottom 11%
Temp (%/°C)
-0.350
Typical · median -0.350
Weight (kg)
28.6
Typical · median 28.4 kg
Warranty (yrs)
25
Weak · bottom 23%

The AmoSolar AS530-560M10-144 series consists of monocrystalline modules based on half-cut cells in M10 format, designed for high power density on a limited surface area. This design minimizes losses under partial shading and improves the stability of the string, which translates into more predictable yields in rooftop and large PV installations.

A key feature of the series is PERC technology, which helps to better utilize radiation in weaker lighting conditions - important in the Polish climate, where frequent cloud cover and variable weather prevail. The modules operate in systems up to 1500 V, making them suitable for commercial and utility-scale projects where optimizing wiring and the number of strings is crucial.

In addition, the series includes an IP68 junction box and standard connectors compatible with popular mounting solutions, which simplifies equipment selection and reduces maintenance time. This is a practical choice for investors who want to combine high power from a single module with reliable performance in operation.

Ranking

706 panels in the segment PERC 500-550 W
Metric This panel Median Position in segment Overall rank
Module efficiency 20.51% 20.90% Weak · bottom 14% 11,268
Power density 205.1 209.0 Weak · bottom 11% 11,321
Temperature coefficient -0.350 -0.350 Typical 10,419
Weight per kWp 54.0 53.0 Typical 8,156
Performance warranty 25 yrs 30 yrs Weak · bottom 23% 9,798
Colour key Strong - top 25% Typical - middle 50% Weak - bottom 25%

Signals from the data

5 positive · 6 caution
Best for

Commercial, utility-scale and shaded-installations.

Not ideal for

Roofs where every square metre has to count, tight roof space and owners who want a long output guarantee.

Watch-outs
205.1 watts per square metre

Bottom 11% of the PERC 500-550 W segment, against a median of 209.0.

20.51% module efficiency

Bottom 14% of the PERC 500-550 W segment, against a median of 20.90%.

25 year performance warranty

Bottom 23% of the PERC 500-550 W segment, against a median of 30 yrs.

What owners get
M10 half-sized poles – lower losses in shaded conditions

The M10 format (182 mm) with a layout of 144 half-cut cells (6x24) reduces the operating current of each cell by half, which limits resistive losses and reduces the impact of partial shading on the string's performance – crucial in rooftop installations with uneven solar exposure.

Efficiency of up to 21.67% – a top-tier PERC level

The upper limit of the series' efficiency (21.67%) is directly comparable to the Premier Energies 144HC PERC modules (21.67%) and is only 0.03% lower than the Exiom EX540-560M (21.7%) and Goldi Solar GS10-B144-GF (21.7%) – indicating a competitive power density for PERC technology.

Operating a 1500 V DC system

Compliance with the 1500 V system voltage allows for the creation of longer strings, reducing the number of cables and inverters in commercial installations and PV farms – directly translating to lower project CAPEX costs.

IP68 connection box

The IP68 level of protection ensures complete protection against water and dust ingress, even during prolonged submersion, which extends the lifespan of connections in the Polish climate (variable temperatures, humidity, and snowfall).

7 power options – flexibility in design

The series includes 7 power levels ranging from 530 to 560 Wp, which allows for precise matching of the modules to the project's established energy balance without the need for over-sizing strings or using optimizers.

Trade-offs
Monofaciality in bifacial solar panels

Direct equivalents – Premier Energies 144HC PERC Bifacial Dual Glass (21.67%) and Goldi Solar GS10-B144-GF (21.7%) – offer bifaciality, which, under ground or on bright roof surfaces, typically provides an additional 5–15% energy yield from the rear surface. The AmoSolar AS530-560M10-144 does not provide this level of gain.

Not classified as Tier-1/bankable (BNEF)

AmoSolar is not listed on the BloombergNEF Tier 1 bankable manufacturers list (verified in Q1 2026). For projects financed by banks or infrastructure funds, the absence of this status may be a disqualifying factor or require additional technology insurance.

12-year product warranty – a declining standard

The warranty on the product is 12 years, while some manufacturers in this segment (e.g., NUUKO for M10 PERC modules) offer 15 years. For commercial installations with a return period greater than 10 years, the difference in warranty coverage could be significant when assessing service-related risks.

Notes from the database
  • Efficiency of 20.5% matches the PERC 500-550W median
  • 205.1 W/m² power density is 3.9 W/m² below PERC 500-550W median (209.0 W/m²) - requires larger installation area
  • At -0.35%/°C, hot weather performance is typical for PERC 500-550W panels
  • In the top 80% for efficiency among all PERC panels

Specifications

Open datasheet PDF
Nominal power (Pmax) 530 Wp Nameplate at 1000 W/m², 25 °C
Module efficiency 20.51 % Weak Segment median 20.90%
Vmpp · Impp 41.86 V · 12.68 A Operating point at max power
Voc · Isc 51.85 V · 13.18 A Sizes the string length
Max system voltage 1500 V Longer strings than 1000 V modules
Dimensions 2279×1134×30 mm · 2.58 m² of roof
Weight 28.6 kg Typical Typical · median 28.4 kg
Cells 144 · PERC Monocrystalline
Coefficient Pmax -0.350 %/°C Typical median -0.350 of its segment
Coefficient Voc · Isc -0.275 · 0.045 %/°C
NOCT 45 °C At 800 W/m², 20 °C ambient
Product warranty 12 years Hardware defects only
Performance warranty 25 years Weak bottom 23% · median 30 yrs
End-of-warranty output 84.8 % Equals 435 W guaranteed
Degradation 2.00 → 0.55 % First year, then annual

Simulations

Live - change any input
Lifetime output & value
30 years at 1200 kWh/kWp/year and €0.50 per kWh
Power in year 30
-
Lifetime energy
-
Energy value
-

Degradation from this panel's own datasheet figures. No inverter, soiling or shading losses.

Heat losses
-0.350 %/°C against a segment median of -0.350
-

Alternatives

All AmoSolar panels
Filter these
Size
Panel Power Eff. Temp. Weight Difference
AmoSolar AS530M10-144 530 W 20.51% -0.350 28.6 kg You are here
LR7-54HJD-510M 510 W 25.00% -0.240 23.5 kg Cooler, lighter, +4.5 pp
AIKO-A495-MCE54Mw 495 W 24.80% -0.260 21.0 kg Cooler, lighter, +4.3 pp
LR7-60HVH-560M 560 W 24.80% -0.260 25.0 kg Cooler, +4.3 pp, +5 yr warranty
LR7-54HJD-505M 505 W 24.70% -0.240 23.5 kg Cooler, lighter, +4.2 pp
LR7-60HVH-555M 555 W 24.60% -0.260 25.0 kg Cooler, +4.1 pp, +5 yr warranty
AIKO-A490-MCE54Mw 490 W 24.50% -0.260 21.0 kg Cooler, lighter, +4.0 pp
LR7-54HJD-500M 500 W 24.50% -0.240 23.5 kg Cooler, lighter, +4.0 pp
AS535M10-144 535 W 20.70% -0.350 28.6 kg Very close match
AS540M10-144 540 W 20.89% -0.350 28.6 kg +10 W, +0.4 pp
AS545M10-144 545 W 21.09% -0.350 28.6 kg +15 W, +0.6 pp
AS550M10-144 550 W 21.28% -0.350 28.6 kg +20 W, +0.8 pp
AIKO-A650-MAE72Mw 650 W 25.20% -0.260 27.0 kg +120 W, cooler, +4.7 pp
AIKO-A645-MAE72Mw 645 W 25.00% -0.260 27.0 kg +115 W, cooler, +4.5 pp
AIKO-A640-MAE72Mw 640 W 24.80% -0.260 27.0 kg +110 W, cooler, +4.3 pp
AIKO-A635-MAE72Mw 635 W 24.60% -0.260 27.0 kg +105 W, cooler, +4.1 pp
AIKO-A630-MAH72Dw 630 W 24.40% -0.260 32.5 kg +100 W, cooler, +3.9 pp

Found 2326 panels of the same or similar size to this one, within ±10 mm. See them here Found 2368 panels of the same or similar size to this one, within ±25 mm. See them here Found 2382 panels of the same or similar size to this one, within ±50 mm. See them here Found 2542 panels of the same or similar size to this one, within ±100 mm. See them here

Common questions

6 answered
What warranty is provided for the AmoSolar AS530-560M10-144 panels?
The AS530-560M10-144 series comes with a 12-year product warranty covering material and workmanship defects, along with a 25-year linear power output warranty. This means the manufacturer guarantees a specified minimum energy yield for a quarter of a century. These are standard values for the commercial segment; however, it should be noted that AmoSolar does not appear on the Tier 1 lists maintained by bankability rating agencies.
What is the peak power output of the highest-wattage panel in the AmoSolar AS530-560M10-144 series?
The peak power in this series reaches 560 Wp. This means that just 10 modules together deliver a combined 5.6 kWp of peak power, which corresponds to a typical prosumer installation for a single-family home. The high per-module wattage translates into a lower panel count needed to achieve the target system capacity, thereby reducing installation and cabling costs.
Do the AmoSolar AS530-560M10-144 panels perform well under overcast conditions typical of Poland?
Yes, the PERC (Passivated Emitter and Rear Cell) technology employed in these modules improves efficiency under diffuse and low-irradiance light conditions, which are characteristic of the Polish climate. The half-cut cell design further reduces resistive losses, allowing the panel to operate more efficiently even on cloudy days. In practice, this translates into better annual energy yields compared to older BSF modules.
Is the AS530-560M10-144 series suitable for large-scale photovoltaic farms?
Yes, the series is designed to operate in systems with a maximum system voltage of 1500 V DC, which is the standard for commercial and utility-scale installations. The higher system voltage allows for longer string configurations, reducing the number of inverters required and lowering overall cabling costs. MC4-compatible connectors and an IP68-rated junction box facilitate rapid field installation.
Are the AmoSolar AS530-560M10-144 modules bifacial?
No, the AS530-560M10-144 series consists of monofacial modules. Energy is generated exclusively by the front cell surface, meaning these modules do not benefit from albedo light reflected off the ground surface, as bifacial modules do. This is well-suited to standard rooftop installations, where the bifacial gain would be negligible anyway due to the close proximity of the roof surface.
Are the AmoSolar AS530-560M10-144 panels compatible with standard mounting systems?
Yes, the AS530-560M10-144 series is equipped with standard MC4-compatible connectors that are compatible with the mounting solutions widely available on the Polish market. The junction box meets the IP68 ingress protection rating, ensuring weather resistance in both rooftop and ground-mounted installations. No non-standard hardware is required for the mounting accessories, which simplifies project logistics.
