Solid all-round for its segment
The Horizon CMD-144BDS series consists of modules designed specifically for carport canopies and other overhead structures, where the panel doubles as a roofing element. Its n-Type TOPCon half-cut cells deliver stable long-term energy output, while the bifacial double-glass construction captures reflected irradiance from the ground below, boosting the overall yield of the installation. What genuinely sets this series apart from competitors is its DIBt certification, confirming compliance with German building-safety standards, including an extended adhesion test that verifies module safety when mounted overhead. The panels also offer high mechanical resistance to snow, wind, and hail impact loads, and are further protected against salt corrosion, sand, and ammonia exposure, making them suitable for demanding environmental conditions. Thanks to partial transparency, the module lets some light pass through, creating a natural dappled-shade effect under the carport rather than complete darkness. This makes it a strong fit for developers looking for panels that combine energy generation with a structural, building-integrated role, backed by a 30-year performance warranty.
Ranking
Signals from the data
Commercial, shaded-installations and BIPV.
The module holds German DIBt certification, including extended laminate adhesion testing, confirming structural safety for overhead installation above pedestrian walkways and parking areas. None of the peer comparables (Talesun, Horay Solar, SunEvo) highlight this certification as a differentiator.
N-Type TOPCon technology, rather than legacy PERC, delivers lower LID/LeTID degradation and better high-temperature performance (temperature coefficient of -0.29%/°C), translating into higher real annual yield, especially on sun-exposed carport structures during summer.
The manufacturer guarantees over 87% of nominal power retained after 30 years - a longer term than the standard 25-year warranties common in the PERC module segment, at a comparable peak power range (570-590 Wp) to peers Talesun and Horay Solar (590 Wp).
The module carries Class 4 hail resistance and Class A fire rating, and is additionally resistant to salt mist corrosion, sand, and ammonia. This is a meaningful advantage for open, weather-exposed carport installations compared to standard rooftop modules without this rating.
AE Solar is a German manufacturer operating since 2003, classified as bankable Tier-1, reducing risk related to warranty and service continuity compared to less established brands in this segment.
The design's partial light transparency and reinforcement for carport roof loading make this a niche product - it is not an optimal choice for standard rooftop or ground-mount installations, where cheaper monofacial modules deliver comparable yield at lower cost.
Maximum power of 590 Wp and efficiency of 22.86% are essentially on par with competing bifacial TOPCon series (Talesun TM7G72M - 590 Wp/22.8%; Horay Solar HS 182-144 TC-D - 590 Wp/22.8%; SunEvo SE5-72H - 590 Wp/22.83%), meaning the price premium for DIBt certification and structural function does not translate into an energy yield advantage.
- At 22.5% efficiency, this panel is on par with typical TOPCon 550-600W modules
- Power density of 224.7 W/m² matches the TOPCon 550-600W median
- Temperature coefficient of -0.29%/°C matches the TOPCon 550-600W median
- Bifaciality factor of 80% can add 4-12% extra yield with reflective mounting surface
- In the top 33% for efficiency among all TOPCon panels
Specifications
Datasheet charts
Measured curves published by AE Solar in this model's datasheet. A chart carrying a wattage was measured on that variant alone - only the ones that describe 580 Wp appear here. The rest cover the whole series.
Simulations
Degradation from this panel's own datasheet figures. No inverter, soiling or shading losses.
Model: bifaciality × albedo × 0.6 view factor. A first-order estimate, not a yield simulation.
Found 2327 panels of the same or similar size to this one, within ±10 mm. See them here Found 2369 panels of the same or similar size to this one, within ±25 mm. See them here Found 2383 panels of the same or similar size to this one, within ±50 mm. See them here Found 2548 panels of the same or similar size to this one, within ±100 mm. See them here
About the CMD-144BDS series
These answers cover the whole series. Where a figure differs, the specification above is this module's own.
