540Wp
Longi Solar Review

LR7-60HVH-540M

Monocrystalline
23.90%
Efficiency
239.3 Wp/m²
Power Density
-0.260%/°C
Temp. Coeff. Pmax chart
480W from 540W
Power after 30 years
  • 23.9% module efficiency - 1.3pp better than the N-type 500-550W median of 22.6%
  • 239.3 W/m² power density - 14.0 W/m² more than N-type 500-550W median (225.3 W/m²), more power per roof area
  • At -0.26%/°C (vs median -0.29%/°C), loses ~1% less power in hot conditions
  • 25.0 kg weight - 1.5 kg lighter than N-type 500-550W median (26.5 kg), reducing installation effort
  • #245 for efficiency, #457 for temperature performance out of 11672 panels
Performance Profile
Price Offers 0
Shop Country Price Price/kWp
Series Hi-MO X10 Scientist LR7-60HVH 535~560M 6 variants
Efficiency Range 23.7% - 24.8%
Avg. Efficiency 24.27%
Technology N-type
Dimensions 1990 × 1134 mm
Show series description

The Longi Solar Hi-MO X10 Scientist LR7-60HVH 535~560M series is designed to maximize energy yield from every square meter – especially in locations with limited roof space or where high power in a compact format is essential. A key feature is the application of back-contact (BC) technology in the enhanced HPBC 2.0 architecture, which translates to better performance under strong sunlight and an attractive, uniform front appearance without visible busbars. The modules utilize N-type cells, which help minimize power losses over time and maintain high efficiency for an extended operational lifespan. An additional benefit is the lower operating temperature, crucial during summer months and on roofs with poor ventilation – more energy reaches the inverter instead of being converted into heat. This series is suitable for residential and commercial installations, as well as projects requiring enhanced mechanical durability and flexible mounting methods while ensuring high reliability.

Panels from the same series differ mainly in power output while having identical dimensions. Learn why →
Electrical Parameters (STC)
Nominal Power (Pmax)540 Wp
Module Efficiency23.90%
Voltage at Max Power (Vmpp)37.11 V
Current at Max Power (Impp)14.55 A
Open Circuit Voltage (Voc)44.88 V
Short Circuit Current (Isc)15.25 A
Max System Voltage1500 V
Temperature Coefficients
Temp. Coeff. Pmax-0.260%/°C
Temp. Coeff. Voc-0.200%/°C
Temp. Coeff. Isc0.050%/°C
NOCT45°C
Cell Technology
Cell TypeMonocrystalline
Cell Count120
BifacialNo
Bifaciality Factor-
Dimensions & Weight
Length1990 mm
Width1134 mm
Height30 mm
Weight25.0 kg
Area2.26 m²
Power Density239.3 Wp/m²
Warranty
Product Warranty15 years
Performance Warranty30 years
End-of-Warranty Output88.8%
First Year Degradation1.00%
Annual Degradation0.35%/year
Key Specifications
23.90%
Efficiency
540 Wp
Power
-0.26%/°C
Temp Coeff
30 yrs
Warranty
