Tongwei TWMNF-66HD745 vs Tongwei TWMNH-66HD655
VS
The verdict
8 differences, and they point both ways
The largest is rated power: 90 W more power. 11 of 19 comparable parameters are identical.
See all 8 differencesHow alike are they
11
of 19 comparable
parameters are identical
parameters are identical
identical
differs
01
8 of 19 parameters
What actually differs
Parameter
TWMNF-66HD745
TWMNH-66HD655
Difference
Rated power
745 Wp
655 Wp
90 W more power
Weight
37.3 kg
32.2 kg
5.1 kg lighter
Short-circuit current
18.87 A
16.52 A
2.35 A apart
Module area
3.106 m²
2.701 m²
0.405 m² apart
Cell technology
TOPCon
N-type
TOPCon vs N-type
Module efficiency
24.00 %
24.20 %
0.20 pp more efficient
Current at max power
17.80 A
15.68 A
2.12 A apart
Dimensions
2384x1303x33 mm
2382x1134x30 mm
2384x1303x33 mm vs 2382x1134x30 mm
02
What it means on a roof
Thirty years of production
Each panel's own declared degradation curve, at 1,200 kWh/kWp a year
Same temp coeff. for both panels (-0.280 %/°C), so a warmer roof scales both curves by the same factor: the totals fall together and neither panel gains on the other.
TWMNF-66HD745
24,996 kWh
TWMNH-66HD655
21,977 kWh
Lifetime gap
3,019 kWh
Output when it is hot
Rated power carried across the range a module actually sees
Scenario
TWMNF-66HD745
TWMNH-66HD655
Standard test conditions
25 °C
100.0% of rated power
745 W
655 W
Cool, bright day
40 °C
95.8% of rated power
714 W
627 W
Typical summer roof
55 °C
91.6% of rated power
682 W
600 W
Hot roof
70 °C
87.4% of rated power
651 W
572 W
03
Full specification
Parameter
TWMNF-66HD745
TWMNH-66HD655
Difference
Power and efficiency
Rated power
745 Wp
655 Wp
+90 W for TWMNF-66HD745
Module efficiency
24.00 %
24.20 %
+0.20 pp for TWMNH-66HD655
Power density
239.8 Wp/m²
242.5 Wp/m²
Effectively the same
Open-circuit voltage
49.95 V
50.15 V
Effectively the same
Voltage at max power
41.86 V
41.78 V
Effectively the same
Short-circuit current
18.87 A
16.52 A
2.35 A apart
Current at max power
17.80 A
15.68 A
2.12 A apart
Temperature
Temperature coefficient
-0.280 %/°C
-0.280 %/°C
Same
Mechanical
Dimensions
2384x1303x33 mm
2382x1134x30 mm
2384x1303x33 mm vs 2382x1134x30 mm
Module area
3.106 m²
2.701 m²
0.405 m² apart
Weight
37.3 kg
32.2 kg
-5.1 kg for TWMNH-66HD655
Weight per kWp
50.1 kg/kWp
49.2 kg/kWp
Effectively the same
Warranty and degradation
Product warranty
12 yrs
12 yrs
Same
Performance warranty
30 yrs
30 yrs
Same
Annual degradation
0.40 %/yr
0.40 %/yr
Same
Technology
Cell technology
TOPCon
N-type
TOPCon vs N-type
Cell type
Monocrystalline
Monocrystalline
Same
Cell count
132
132
Same
Bifacial
Yes
Yes
Same
04
14,005 panels
Against the whole database
Efficiency
#303
vs
#184
TWMNH-66HD655 leads by 119 places
Power density
#339
vs
#172
TWMNH-66HD655 leads by 167 places
Heat behaviour
#1,309
vs
#1,309
Tied - the same position in the database
Weight
#3,586
vs
#2,776
TWMNH-66HD655 leads by 810 places
Warranty
#21
vs
#21
Tied - the same position in the database
Overall
#148
vs
#992
TWMNF-66HD745 leads by 844 places
05
Open the full database
More useful comparisons
Same series, other bin
Tongwei TWMNF-66HD745 vs Tongwei TWMNF-66HD750
The same specification on paper
Same series, other bin
Tongwei TWMNF-66HD745 vs Tongwei TWMNF-66HD740
One difference: module efficiency
Same series, other bin
Tongwei TWMNF-66HD745 vs Tongwei TWMNF-66HD735
3 differences, the largest is module efficiency
Same series, other bin
Tongwei TWMNF-66HD745 vs Tongwei TWMNF-66HD730
3 differences, the largest is module efficiency
Same series, other bin
Tongwei TWMNH-66HD655 vs Tongwei TWMHF-66HD740X
10 differences, the largest is temperature coefficient
Same series, other bin
Tongwei TWMNH-66HD655 vs Tongwei TWMHF-66HD735X
10 differences, the largest is temperature coefficient
06
Written summary
Checking cache...
07
Questions about this pairing
Which panel is better: Tongwei TWMNF-66HD745 or Tongwei TWMNH-66HD655?
According to our database: Tongwei TWMNH-66HD655 has higher module efficiency (24.20% vs 24.00%). See the full spec comparison and 30-year energy simulation above for a complete picture.
What is the efficiency of Tongwei TWMNF-66HD745 and Tongwei TWMNH-66HD655?
Tongwei TWMNF-66HD745 has a module efficiency of 24.00%, while Tongwei TWMNH-66HD655 is 24.20%. Higher efficiency means more electricity from the same roof area - useful when space is limited.
What cell technology does Tongwei TWMNF-66HD745 use vs Tongwei TWMNH-66HD655?
Tongwei TWMNF-66HD745 uses TOPCon cells; Tongwei TWMNH-66HD655 uses N-type. Modern n-type technologies (TOPCon, HJT, BC) typically deliver higher efficiency and lower degradation compared to older PERC (p-type) cells.
What is the warranty on Tongwei TWMNF-66HD745 and Tongwei TWMNH-66HD655?
Tongwei TWMNF-66HD745 has a 30 years power warranty; Tongwei TWMNH-66HD655 has a 30 years power warranty. The power warranty guarantees a minimum percentage of rated output at the end of the warranty period (typically 80-87%). Product (materials) warranties are usually shorter.
Are Tongwei TWMNF-66HD745 and Tongwei TWMNH-66HD655 bifacial panels?
Both Tongwei TWMNF-66HD745 and Tongwei TWMNH-66HD655 are bifacial - they capture reflected light from the ground, which can add 5-15% more annual energy on ground-mount or elevated rooftop installations with a light surface beneath.
Shop prices: See 53 Tongwei offers
Every figure here is from the manufacturers' own datasheets - a dash means the value is not published, never an estimate. The thirty-year projection and the temperature scenarios are calculations from those figures, and each states its assumption above.
