AmoSolar AS495M10-132

AS495M10-132

495 Wp PERC
ComparePV verdict

Light for its output, no clear weak spot

Rank 10,113 of 14,005
Compare panels Datasheet PDF
Power (Wp)
495
Strong · top 5%
Efficiency (%)
20.85
Typical · median 20.82%
Density (Wp/m²)
208.5
Typical · median 208.5
Temp (%/°C)
-0.350
Typical · median -0.350
Weight (kg)
24.5
Strong · top 14%
Warranty (yrs)
25
Typical · median 25 yrs

The AmoSolar AS485-515M10-132 FULL BLACK series is designed for installations where both aesthetics and stable performance in challenging conditions are important. The use of monocrystalline M10 modules and a 132-cell layout promotes high power density while maintaining good module performance. The FULL BLACK version makes it easier to aesthetically match with dark tiles, metal roofing, or modern facades, so that the panels do not visually dominate the building's structure.

This is a solution for investors who want to minimize energy losses during hot weather - this is facilitated by the favorable temperature coefficient. The modules are also designed for long-term operation: the high sealing class of the connection box and standard connections that make installation easy play an important role. This series is suitable for single-family homes, company roofs, and projects where aesthetics, durability, and predictable energy yields are a priority.

Ranking

449 panels in the segment PERC 450-500 W
Metric This panel Median Position in segment Overall rank
Module efficiency 20.85% 20.82% Typical 10,362
Power density 208.5 208.5 Typical 10,410
Temperature coefficient -0.350 -0.350 Typical 10,419
Weight per kWp 49.5 53.1 Strong · top 14% 3,033
Performance warranty 25 yrs 25 yrs Typical 9,798
Colour key Strong - top 25% Typical - middle 50% Weak - bottom 25%

Signals from the data

5 positive · 4 caution
Best for

Residential, commercial and hot-climate.

Strengths
49.5 kg per kWp

Top 14% of the PERC 450-500 W segment, against a median of 53.1.

What owners get
Uncompromised Full Black Aesthetics

The uniform black finish across the frame, cells, and backsheet allows the array to blend seamlessly into dark ceramic tile, bituminous, or dark metal roofing. In the residential prosumer and architectural integration segments, this is a decisive sales argument that standard modules with white backsheets simply cannot offer.

M10 Half-Cut Cells (Half-Cut 132)

The 132-cell half-cut M10 (182 mm) layout splits the module into two independent electrical circuits, reducing resistive losses by approximately 50% compared to full-cell designs and significantly limiting the impact of partial shading on one half of the module from affecting the other. This translates into a tangible real-world benefit on rooftops with chimneys or dormers.

Competitive Efficiency for a PERC Full Black Module

A peak efficiency of 21.69% with a fully black aesthetic places this series above the typical 20–21% range for PERC Full Black modules. Since a standard white backsheet reflects heat more effectively, achieving 21.69% with a black backsheet indicates well-managed cell operating temperatures in this module design.

25-Year Linear Power Warranty

The manufacturer guarantees a linear power degradation profile over 25 years — a standard aligned with premium-segment market norms. For residential prosumer systems in the typical 8–12 kWp range, this provides predictable energy yield throughout the full system payback period.

Trade-offs
Efficiency Trails Peer Comparables by 1.1–1.6 pp

At a maximum efficiency of 21.69%, this series falls noticeably short of direct competitors in the same power class: Canadian Solar TOPBiHiKu6 reaches 22.8%, Huasun Aurora Pro 23.17%, and Jolywood JW-HD120N 23.3%. A gap of 1.1–1.6 percentage points translates to approximately 5–7% less power harvested from the same roof area under identical irradiance conditions.

P-type PERC Technology vs. N-type TOPCon/HJT Competitors

All three peer comparables use N-type cells (TOPCon or HJT), which carry a lower Pmax temperature coefficient (TOPCon: approx. −0.29%/°C; HJT: approx. −0.25%/°C) versus the typical −0.35%/°C for P-type PERC. In the Polish climate, where modules regularly reach 60–70°C in summer, this difference results in approximately 1.5–2.5% higher real annual energy losses. P-type PERC also exhibits a higher susceptibility to LeTID (Light and elevated Temperature Induced Degradation) than N-type technologies.

12-Year Product Warranty — Below Tier-1 Standard

The product warranty stands at 12 years, whereas leading Tier-1 manufacturers such as Jinko Solar and LONGi offer 15 years — and in some product lines up to 25 years. On systems backed by a 25-year linear power warranty, the mid-life operating period (years 13–25) is left without coverage against manufacturing defects, materially increasing the owner's potential service and replacement costs.

Not Tier-1 / Bankable Status Absent (BNEF Q1 2026)

AmoSolar does not appear on BloombergNEF's bankable manufacturers list (BNEF Tier-1 Q1 2026). For commercial installations or projects requiring debt financing, this may represent a significant barrier — financial institutions and insurers frequently mandate modules from BNEF-listed manufacturers as a condition for loan approval or policy issuance. The risk is lower in the residential prosumer segment, but it does affect the residual value of the installation upon a potential property sale.

Notes from the database
  • Efficiency of 20.9% matches the PERC 450-500W median
  • At 208.5 W/m² power density, roof space requirements are typical for PERC 450-500W panels
  • Temperature coefficient of -0.35%/°C matches the PERC 450-500W median
  • In the top 74% for efficiency among all PERC panels

Specifications

Open datasheet PDF
Nominal power (Pmax) 495 Wp Nameplate at 1000 W/m², 25 °C
Module efficiency 20.85 % Typical Segment median 20.82%
Vmpp · Impp 38.50 V · 12.87 A Operating point at max power
Voc · Isc 47.74 V · 13.33 A Sizes the string length
Max system voltage 1500 V Longer strings than 1000 V modules
Dimensions 2094×1134×30 mm · 2.37 m² of roof
Weight 24.5 kg Strong Strong · top 14%
Cells 132 · PERC Monocrystalline
Coefficient Pmax -0.350 %/°C Typical median -0.350 of its segment
Coefficient Voc · Isc -0.275 · 0.045 %/°C
NOCT 45 °C At 800 W/m², 20 °C ambient
Product warranty 12 years Hardware defects only
Performance warranty 25 years Typical median 25 yrs · median 25 yrs
End-of-warranty output 84.8 % Equals 406 W guaranteed
Degradation 2.00 → 0.55 % First year, then annual

Simulations

Live - change any input
Lifetime output & value
30 years at 1200 kWh/kWp/year and €0.50 per kWh
Power in year 30
-
Lifetime energy
-
Energy value
-

Degradation from this panel's own datasheet figures. No inverter, soiling or shading losses.

Heat losses
-0.350 %/°C against a segment median of -0.350
-

Alternatives

All AmoSolar panels
Filter these
Size
Panel Power Eff. Temp. Weight Difference
AmoSolar AS495M10-132 495 W 20.85% -0.350 24.5 kg You are here
LR7-54HJD-510M 510 W 25.00% -0.240 23.5 kg Cooler, +4.1 pp, +5 yr warranty
AIKO-A495-MCE54Mw 495 W 24.80% -0.260 21.0 kg Cooler, +3.9 pp, +5 yr warranty
LR7-54HJD-505M 505 W 24.70% -0.240 23.5 kg Cooler, +3.8 pp, +5 yr warranty
AIKO-A490-MCE54Mw 490 W 24.50% -0.260 21.0 kg Cooler, +3.6 pp, +5 yr warranty
LR7-54HJD-500M 500 W 24.50% -0.240 23.5 kg Cooler, +3.6 pp, +5 yr warranty
CIPRO-TN9C54M-500W 500 W 24.50% -0.260 21.4 kg Cooler, +3.6 pp, +5 yr warranty
AS485M10-132 485 W 20.42% -0.350 24.5 kg -10 W, -0.4 pp
AS490M10-132 490 W 20.64% -0.350 24.5 kg -0.2 pp
AS500M10-132 500 W 21.06% -0.350 24.5 kg +0.2 pp
AS505M10-132 505 W 21.27% -0.350 24.5 kg +10 W, +0.4 pp
AS510M10-132 510 W 21.48% -0.350 24.5 kg +15 W, +0.6 pp
AS515M10-132 515 W 21.69% -0.350 24.5 kg +20 W, +0.8 pp
GKA120N-PRO-590W 590 W 23.82% -0.300 26.7 kg +95 W, +3.0 pp, +5 yr warranty
GKA120N-PRO-585W 585 W 23.62% -0.300 26.7 kg +90 W, +2.8 pp, +5 yr warranty
BGO 580 580 W 23.50% -0.290 26.0 kg +85 W, cooler, +2.6 pp
GKA120N-PRO-580W 580 W 23.42% -0.300 26.7 kg +85 W, +2.6 pp, +5 yr warranty

Found 397 panels of the same or similar size to this one, within ±10 mm. See them here Found 408 panels of the same or similar size to this one, within ±25 mm. See them here Found 425 panels of the same or similar size to this one, within ±50 mm. See them here Found 953 panels of the same or similar size to this one, within ±100 mm. See them here

Common questions

6 answered
What is the maximum power output of the AmoSolar AS485-515M10-132 FULL BLACK panel, and is 515 Wp a competitive figure?
The peak power of modules in this series reaches 515 Wp, which is a solid result for a monocrystalline PERC panel in the M10 format with a 132-cell layout. This translates into high power density per square meter, meaning the installation requires less roof area than older modules of comparable total output. It is a strong choice for rooftops with limited usable surface.
What is the PERC technology used in the AS485-515M10-132 series, and is the price premium justified?
PERC (Passivated Emitter and Rear Cell) is a technology that adds a light-reflecting layer to the rear side of the cell, increasing solar energy conversion efficiency. In practice, this results in higher energy yields under diffuse light conditions and lower temperature-induced power losses during hot weather. For a typical residential installation, PERC delivers better annual energy yield than older BSF cells at a comparable module price point.
Do AmoSolar FULL BLACK panels perform worse at high temperatures in summer?
The all-black finish does absorb slightly more heat than a silver frame, however the AS485-515M10-132 series benefits from the favorable temperature coefficient characteristic of M10 PERC cells, which limits power losses during heat. In practice, the yield difference between a FULL BLACK panel and a standard-frame equivalent is marginal, and for most system owners it is outweighed by the aesthetic appeal and better architectural integration with the roofline.
What warranty coverage applies to the AmoSolar AS485-515M10-132 FULL BLACK series?
The manufacturer provides a 12-year product warranty covering material defects and workmanship, along with a 25-year linear power output warranty. After 25 years of operation, the module is expected to retain the manufacturer-specified percentage of its nominal power. Before purchasing, it is advisable to confirm that the distributor supplies the original warranty card, as this is required to file a valid warranty claim.
Is the AmoSolar FULL BLACK series suitable for dark roof tiles or modern building facades?
Yes, the AS485-515M10-132 FULL BLACK series was designed precisely for such applications. The black frame, black cells, and black backsheet create a uniform appearance that integrates well with anthracite roof tiles, dark metal roofing, or contemporary building facades. The panels do not visually dominate the building's silhouette and are frequently selected by owners for whom installation aesthetics are a priority.
Is AmoSolar a Tier 1 manufacturer, and does that matter when selecting panels?
AmoSolar does not currently appear on the Tier 1 lists published by agencies such as BloombergNEF, which assess manufacturer bankability rather than module quality directly. For residential customers, the more relevant factors are the warranty terms, the availability of after-sales service from the local distributor, and technical parameters confirmed by IEC certifications. Before purchasing, it is worth verifying that the local distributor provides post-sale support and handles warranty claims on behalf of the end customer.
