Horay Solar HS510TC-MHA-D vs Longi Solar LR7-54HVH-475M
VS
The verdict
LR7-54HVH-475M leads on the differences that matter
The largest is rated power: 35 W more power. 6 of 19 comparable parameters are identical.
See all 13 differencesHow alike are they
6
of 19 comparable
parameters are identical
parameters are identical
identical
differs
01
13 of 19 parameters
What actually differs
Parameter
HS510TC-MHA-D
LR7-54HVH-475M
Difference
Rated power
510 Wp
475 Wp
35 W more power
Weight
26.0 kg
21.6 kg
4.4 kg lighter
Temperature coefficient
-0.280 %/°C
-0.260 %/°C
0.020 %/°C better in heat
Weight per kWp
51.0 kg/kWp
45.5 kg/kWp
5.5 kg/kWp lighter
Module area
2.217 m²
2.041 m²
0.176 m² apart
Open-circuit voltage
44.10 V
40.18 V
3.92 V apart
Cell technology
TOPCon
N-type
TOPCon vs N-type
Module efficiency
23.10 %
23.30 %
0.20 pp more efficient
Annual degradation
0.40 %/yr
0.35 %/yr
0.05 %/yr slower
Cell count
120
108
12 cells apart
Voltage at max power
36.80 V
33.16 V
3.64 V apart
Bifacial
Yes
No
Yes vs No
Dimensions
1955x1134x30 mm
1800x1134x30 mm
1955x1134x30 mm vs 1800x1134x30 mm
02
What it means on a roof
Thirty years of production
Each panel's own declared degradation curve, at 1,200 kWh/kWp a year
HS510TC-MHA-D
17,112 kWh
LR7-54HVH-475M
16,061 kWh
Lifetime gap
1,051 kWh
Output when it is hot
Rated power carried across the range a module actually sees
Scenario
HS510TC-MHA-D
LR7-54HVH-475M
Standard test conditions
25 °C
100.0% of rated power
510 W
475 W
Cool, bright day
40 °C
95.8% of rated power
489 W
456 W
Typical summer roof
55 °C
91.6% of rated power
467 W
438 W
Hot roof
70 °C
87.4% of rated power
446 W
419 W
03
Full specification
Parameter
HS510TC-MHA-D
LR7-54HVH-475M
Difference
Power and efficiency
Rated power
510 Wp
475 Wp
+35 W for HS510TC-MHA-D
Module efficiency
23.10 %
23.30 %
+0.20 pp for LR7-54HVH-475M
Power density
230.0 Wp/m²
232.7 Wp/m²
Effectively the same
Open-circuit voltage
44.10 V
40.18 V
3.92 V apart
Voltage at max power
36.80 V
33.16 V
3.64 V apart
Short-circuit current
14.64 A
15.03 A
Effectively the same
Current at max power
13.86 A
14.33 A
Effectively the same
Temperature
Temperature coefficient
-0.280 %/°C
-0.260 %/°C
+0.020 %/°C for LR7-54HVH-475M
Mechanical
Dimensions
1955x1134x30 mm
1800x1134x30 mm
1955x1134x30 mm vs 1800x1134x30 mm
Module area
2.217 m²
2.041 m²
0.176 m² apart
Weight
26.0 kg
21.6 kg
-4.4 kg for LR7-54HVH-475M
Weight per kWp
51.0 kg/kWp
45.5 kg/kWp
-5.5 kg/kWp for LR7-54HVH-475M
Warranty and degradation
Product warranty
15 yrs
15 yrs
Same
Performance warranty
30 yrs
30 yrs
Same
Annual degradation
0.40 %/yr
0.35 %/yr
-0.05 %/yr for LR7-54HVH-475M
Technology
Cell technology
TOPCon
N-type
TOPCon vs N-type
Cell type
Monocrystalline
Monocrystalline
Same
Cell count
120
108
12 cells apart
Bifacial
Yes
No
Yes vs No
04
14,005 panels
Against the whole database
Efficiency
#1,570
vs
#1,017
LR7-54HVH-475M leads by 553 places
Power density
#2,133
vs
#1,189
LR7-54HVH-475M leads by 944 places
Heat behaviour
#1,309
vs
#511
LR7-54HVH-475M leads by 798 places
Weight
#4,341
vs
#743
LR7-54HVH-475M leads by 3,598 places
Warranty
#21
vs
#21
Tied - the same position in the database
Overall
#5,464
vs
#6,386
HS510TC-MHA-D leads by 922 places
05
Open the full database
More useful comparisons
Same series, other bin
Horay Solar HS510TC-MHA-D vs Horay Solar HS505TC-MHA-D
One difference: module efficiency
Same series, other bin
Horay Solar HS510TC-MHA-D vs Horay Solar HS500TC-MHA-D
3 differences, the largest is module efficiency
Same series, other bin
Horay Solar HS510TC-MHA-D vs Horay Solar HS495TC-MHA-D
3 differences, the largest is module efficiency
Same series, other bin
Horay Solar HS510TC-MHA-D vs Horay Solar HS490TC-MHA-D
4 differences, the largest is module efficiency
Same manufacturer
Horay Solar HS510TC-MHA-D vs Horay Solar HS720TC-MHG-D
10 differences, the largest is rated power
Same manufacturer
Horay Solar HS510TC-MHA-D vs Horay Solar HS710TC-MHG-D
11 differences, the largest is rated power
06
Written summary
Checking cache...
07
Questions about this pairing
Which panel is better: Horay Solar HS510TC-MHA-D or Longi Solar LR7-54HVH-475M?
According to our database: Longi Solar LR7-54HVH-475M has higher module efficiency (23.30% vs 23.10%); Longi Solar LR7-54HVH-475M tolerates heat better (temp coeff -0.260%/°C vs -0.280%/°C). See the full spec comparison and 30-year energy simulation above for a complete picture.
What is the efficiency of Horay Solar HS510TC-MHA-D and Longi Solar LR7-54HVH-475M?
Horay Solar HS510TC-MHA-D has a module efficiency of 23.10%, while Longi Solar LR7-54HVH-475M is 23.30%. Higher efficiency means more electricity from the same roof area - useful when space is limited.
What cell technology does Horay Solar HS510TC-MHA-D use vs Longi Solar LR7-54HVH-475M?
Horay Solar HS510TC-MHA-D uses TOPCon cells; Longi Solar LR7-54HVH-475M uses N-type. Modern n-type technologies (TOPCon, HJT, BC) typically deliver higher efficiency and lower degradation compared to older PERC (p-type) cells.
What is the warranty on Horay Solar HS510TC-MHA-D and Longi Solar LR7-54HVH-475M?
Horay Solar HS510TC-MHA-D has a 30 years power warranty; Longi Solar LR7-54HVH-475M has a 30 years power warranty. The power warranty guarantees a minimum percentage of rated output at the end of the warranty period (typically 80-87%). Product (materials) warranties are usually shorter.
Are Horay Solar HS510TC-MHA-D and Longi Solar LR7-54HVH-475M bifacial panels?
Horay Solar HS510TC-MHA-D is bifacial (captures light from both faces); Longi Solar LR7-54HVH-475M is monofacial. Bifacial panels work best on ground mounts or raised structures with a light-coloured surface underneath.
Shop prices: See 174 Longi Solar offers
Every figure here is from the manufacturers' own datasheets - a dash means the value is not published, never an estimate. The thirty-year projection and the temperature scenarios are calculations from those figures, and each states its assumption above.
